Standards | IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11n/b/g 2,4 GHz |
---|---|
Ports | 1x 10/100/1000 Mbps RJ-45 (LAN), 1x 10/100/1000 Mbps RJ-45 (WAN), 1 port USB 2.0 |
Frequency range | 2,4GHz and 5GHz |
Modulation | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
Operating modes | AP Router |
Max. speed | 5 GHz@ 1201 Mb/s (802.11ax), 2,4 GHz@ 300 Mb/s (802.11n) |
Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
WLAN security | 64/128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
WAN Type | Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
Management | Access Control, Local Management, Remote Management |
DHCP | Server, DHCP Client List |
Port Forwarding | Virtual Server, UPnP, DMZ |
Dynamic DNS | DynDns, NO-IP |
Access Control | Parental Controls, Local Management Control, Host List, Access Schedule, Rule Management |
Firewall Security | DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
Protocols | IPv4, IPv6 |
Guest Network | 1× 2.4 GHz Guest Network, 1× 5 GHz Guest Network |
Dimensions | 4.09 × 3.54 × 1.10 in (104 × 90 × 28 mm) |
Operating temperatures | 0°C ÷ 40°C |
Operating humidity | 10% ÷ 90%, non-condensing |
Power | 12 V DC / 1,5 A |
Certificates | CE, RoHS |
Manufacturer | TP-Link |
