TP-LINK

TP-LINK Products

TP-LINK - Networking products

TP-LINK
TP-LINK
TP-LINK is a largest Chinese network hardware manufacturer for SOHO market. Company was founded in 1996. Their market share in networking products is still growing. TP-LINK cooperates with over 600 distributors in China and rest of the world. There are over 100 experienced engineers working for TP-LINK in two factories with 21 production lines. Perfect technical support and management system compliant with ISO9001:2000 gives warranty of reliability and stability of their devices. Quality of products was confirmed with a lot of awards in many independent device tests. TP-LINK is also manufacturing OEM versions of hardware for other network device manufacturers.

TP-LINK offers includes:
  • access points
  • routers
  • network cards
  • switches
  • media converters
  • modems

Manufacturer's website: http://www.tp-link.com

  • Computer Network Accessories
    • Switches
      • » GIGABIT ETHERNET / INTELLIGENT (SMART SWITCHES)
          #09139

          Smart switch, 8x 10/100/1000 RJ-45, desktop (TP-Link TL-SG2008)

          • Full Gigabit Ports: 8× gigabit RJ45 ports provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Robust Security Strategies: 802.1Q VLAN, ACL, Port Security, Storm Control, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
          Standards IEEE 802.3/i/u/ab/ad/x/d/s/w/q/p
          Copper ports 8x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
          Performance
          Bandwidth/Backplane 16Gbps
          MAC Address Table 8k
          Packet Forwarding Rate 11.9Mpps
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 Features IGMP Snooping V1/V2/V3,
          802.3ad LACP (Up to 6 aggregation groups,
          containing 4 ports per group),
          Spanning Tree STP/RSTP/MSTP,
          LLDP,
          LLDP-Med,
          BPDU Filtering/Guard,
          TC/Root Protect,
          Loop back detection,
          802.3x Flow Control,
          VLAN Voice
          VLAN Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
          Security SSH v1/v2,
          SSL v2/v3/TLSv1,
          Port Security,
          Broadcast/Multicast/Unknown-unicast Storm Control
          Management Web-based GUI and CLI management,
          SNMP v1/v2c/v3, compatible with public MIBs and TP-LINK private MIBs,
          RMON (1, 2, 3, 9 groups),
          DHCP/BOOTP Client, DHCP Filtering,
          CPU Monitoring,
          Port Mirroring,
          Time Setting- SNTP,
          System Diagnose- VCT,
          SYSLOG & Public MIBS
          Firmware Upgrade TFTP & Web
          Dimensions 8.2x4.9x1.0 in. (209x126x26mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 12 VDC/1 A External Adapter or Obtain Power from PoE Source
          Power Consumption 6.4 W (220 V/50 Hz)
          Fan Quantity Fanless
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 8x 10/100/1000 RJ-45, desktop (TP-Link TL-SG2008)
          Net Price: 68,90 EUR
          product card»
          #09140

          Smart switch, 8x 10/100/1000 RJ-45, PoE+, desktop (TP-Link TL-SG2008P)

          • 62 W PoE Budget: 4× 802.3at/af-compliant PoE+ ports with a total power supply of 62 W*.
          • Full Gigabit Ports: 4× gigabit PoE+ ports and 4× gigabit non-PoE ports provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          Standards IEEE 802.3/i/u/ab/ad/x/d/s/w/q/p
          Copper ports 8x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
          PoE Ports (RJ45) Standard 802.3af/at compliant,
          PoE Ports 4 Ports,
          Power Supply 62 W
          Performance
          Bandwidth/Backplane 16Gbps
          MAC Address Table 8k
          Packet Buffer Memory 4.1 Mbit
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 Features IGMP Snooping V1/V2/V3,
          802.3ad LACP (Up to 6 aggregation groups,
          containing 4 ports per group),
          Spanning Tree STP/RSTP/MSTP,
          LLDP,
          LLDP-Med,
          BPDU Filtering/Guard,
          TC/Root Protect,
          Loop back detection,
          802.3x Flow Control,
          VLAN Voice
          VLAN Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
          Security SSH v1/v2,
          SSL v2/v3/TLSv1,
          Port Security,
          Broadcast/Multicast/Unknown-unicast Storm Control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Dimensions 8.2x4.9x1.0 in. (209x126x26mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power External Power Adapter (Output 53.5 VDC/ 1.31 A)
          Power Consumption 7.9W (220 V/50 Hz),
          79.2 W (220 V/50 Hz) (with 62 W PD connected)
          Fan Quantity Fanless
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 8x 10/100/1000 RJ-45, PoE+, desktop (TP-Link TL-SG2008P)
          Net Price: 84,10 EUR
          product card»
          #09142

          Smart switch, 8x 10/100/1000 RJ-45, PoE+, desktop (TP-Link TL-SG2210P)

          • 61 W PoE Budget: 8× 802.3af/at-compliant PoE+ ports with a total power supply of 61 W*.
          • Full Gigabit Ports: 8× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimized Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
          Standards IEEE 802.3/i/u/ab/ad/x/d/s/w/q/p
          Copper ports 8x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
          PoE Ports (RJ45) Standard 802.3af/at compliant,
          PoE Ports 8 Ports,
          Power Supply 61 W
          Performance
          Bandwidth/Backplane 20Gbps
          Packet Forwarding Rate 14.88 Mpps
          MAC Address Table 8k
          Packet Buffer Memory 4.1 Mbit
          Jumbo Frame 9 KB
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 Features IGMP Snooping V1/V2/V3,
          802.3ad LACP (Up to 6 aggregation groups,
          containing 4 ports per group),
          Spanning Tree STP/RSTP/MSTP,
          LLDP,
          LLDP-Med,
          BPDU Filtering/Guard,
          TC/Root Protect,
          Loop back detection,
          802.3x Flow Control,
          VLAN Voice
          VLAN Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
          Security SSH v1/v2,
          SSL v2/v3/TLSv1,
          Port Security,
          Broadcast/Multicast/Unknown-unicast Storm Control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Dimensions 8.2x4.9x1.0 in. (209x126x26mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power External Power Adapter (Output 53.5 VDC/ 1.31 A)
          Power Consumption 10,5 W (220 V/50 Hz),
          75,3 W (220 V/50 Hz) (with 58 W PD connected)
          Fan Quantity Fanless
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 8x 10/100/1000 RJ-45, PoE+, desktop (TP-Link TL-SG2210P)
          Net Price: 111,00 EUR
          product card»
          #08534

          Smart switch, 8x 10/100/1000 RJ-45, desktop (TP-Link TL-SG108E)

          Standards IEEE 802.3,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 8x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Packet flow control Flow-Control,
          Back-Pressure
          MAC Address Table 8K
          Packet Buffer Memory 2Mb
          Packet Forwarding Rate 11.9Mpps
          Jumbo Frame 16KB
          Quality of Service Support Port Based/802.1p Based priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping,
          Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention
          VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Transmission Method Store-And-Forward
          Housing / case type desktop,
          metal
          Dimensions 158x101x25 mm (6.2x4.0x1.0 cala)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240VAC,
          50/60Hz
          Certificates CE,
          FCC,
          RoHS
          Warranty 5 years
          Manufacturer TP-Link
          Smart switch, 8x 10/100/1000 RJ-45, desktop (TP-Link TL-SG108E)
          Net Price: 21,20 EUR
          product card»
          #04669

          Smart switch, 8x 10/100/1000 RJ-45, PoE, desktop (TP-Link TL-SG108PE)

          • 8 10/100/1000Mbps RJ45 ports
          • With 4 PoE ports, data and power can be transferred on one single cable
          • Provides network monitoring, traffic prioritization and VLAN features
          • Simple network set-up on top of plug-and-play connectivity
          • Web-based user interface and Easy Smart Configuration Utility simplify configuration
          Standards IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3af,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 8x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Standard 802.3 af compliant
          PoE Ports Port 1- Port 4
          PoE Power Budget 55W
          Switching architecture / speed Store and Forward
          Packet flow control Flow-Control,
          Back-Pressure
          Switching Capacity 16Gbps
          MAC Address Table 4K
          Packet Buffer Memory 1.5Mb
          Packet Forwarding Rate 11.9Mpps
          Jumbo Frame 16KB
          Quality of Service Support Port Based/802.1p Based priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping,
          Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention
          VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Transmission Method Store-And-Forward
          Housing / case type desktop,
          metal
          Dimensions 158x101x25 mm (6.2x4.0x1.0 cala)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power External Power Adapter(Output 48VDC / 1.25A)
          Power Consumption Maximum (PoE on) 65.2W (220V/50Hz),
          Maximum (PoE off) 5.2W (220V/50Hz)
          Certificates CE,
          FCC,
          RoHS
          Package Contents TL-SG108PE,
          Power Adapter,
          Installation Guide,
          Resource CD,
          Rubber Feet
          System Requirements Microsoft® Windows® for running Utility
          Warranty 5 years
          Manufacturer TP-Link
          Smart switch, 8x 10/100/1000 RJ-45, PoE, desktop (TP-Link TL-SG108PE)
          Net Price: 50,70 EUR
          product card»
          #09267

          Smart switch, 16x 10/100/1000 RJ-45, PoE+ (TP-Link TL-SG2016P)

          • 120 W PoE Budget: 8× 802.3at/af-compliant PoE+ ports with a total power supply of 120 W.
          • Full Gigabit Ports: 8× gigabit PoE+ ports and 8× gigabit non-PoE ports provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          Standards IEEE 802.3i,
          IEEE 802.3ab,
          IEEE 802.3ad,
          IEEE 802.3af,
          IEEE 802.3at,
          IEEE 802.3x,
          IEEE 802.1d,
          IEEE 802.1s,
          IEEE 802.1w,
          IEEE 802.1q,
          IEEE 802.1p,
          IEEE 802.1x
          Copper ports 16x 10/100/1000 Mbps RJ-45 (Ports 1–8 Support 802.3at/af PoE+)
          Fan Quantity Fanless
          PoE Ports Standard 802.3 at compliant,
          PoE Ports Port 1- Port 8,
          Power Supply 120 W
          Performance:
          Bandwidth/Backplane 16 Gbps
          MAC Address Table 8k
          Packet Buffer Memory 4.1 Mbit
          Jumbo Frame 9 KB
          Software features
          Quality of Service 802.1p CoS/DSCP priority,
          8 priority queues,
          Priority Schedule Mode,
          SP (Strict Priority),
          WRR (Weighted Round Robin),
          Queue Weight Config,
          Bandwidth Control,
          Port/Flow-based Rating Limit,
          Smoother Performance,
          Storm Control,
          Multiple Control Modes(kbps/ratio),
          Broadcast/Multicast/Unknown-Unicast Control
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN 12 Entries,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Access Control List Support up to 230 entries,
          Time-Range,
          Time Slice,
          Week Time-Range,
          Absolute Time-Range,
          Holiday,
          Time-based ACL,
          MAC ACL,
          Source MAC,
          Destination MAC,
          VLAN ID,
          User Priority,
          Ether Type,
          IP ACL,
          Source IP,
          Destination IP,
          IP Protocol,
          TCP Flag,
          TCP/UDP Source Port,
          TCP/UDP Destination Port,
          DSCP/IP TOS,
          IPv6 ACL,
          Combined ACL,
          Rule Operation,
          Permit/Deny,
          Policy Action,
          Mirror,
          Rate Limit,
          Redirect,
          QoS Remark,
          ACL Rules Binding,
          Port Binding,
          VLAN Binding,
          Actions for flows,
          Mirror (to supported interface),
          Redirect (to supported interface),
          Rate Limit,
          QoS Remark
          Security AAA,
          802.1X,
          Port-based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC-based access control
          Advanced Features Automatic Device Discovery,
          Batch Configuration,
          Batch Firmware Upgrading,
          Intelligent Network Monitoring,
          Abnormal Event Warnings,
          Unified Configuration,
          Reboot Schedule
          MIBs MIB II (RFC1213),
          Bridge MIB (RFC1493),
          P/Q-Bridge MIB (RFC2674),
          Radius Accounting Client MIB (RFC2620),
          Radius Authentication Client MIB (RFC2618),
          Remote Ping,
          Traceroute MIB (RFC2925),
          Support TP-Link private MIBs,
          RMON MIB(RFC1757,
          rmon 1,2,3,9)
          Management
          Omada App Yes,
          through,
          Omada Cloud-Based Controller,
          OC300,
          OC200,
          Omada Software Controller
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes,
          through,
          Omada Cloud-Based Controller,
          OC300,
          OC200,
          Omada Software Controller
          Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Dimensions 11.3 x 4.4 x 1.0 in. (286 x 111.7 x 25.4 mm)
          Operating Temperature 0℃~40℃ (32℉~104℉)
          Storage Temperature -40℃~70℃ (-40℉~158℉)
          Operating Humidity 10%~90% non-condensing
          Storage Humidity 5%~90% non-condensing
          Power External Power Adapter (Output 53.5 VDC/ 2.43 A)
          Power Consumption 146.5 W (110 V/60 Hz) (with 120 W PD connected)
          Max Heat Dissipation 499.98 BTU/hr (110 V/60 Hz) (with 120 W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty 5 years
          Manufacturer TP-Link
          Smart switch, 16x 10/100/1000 RJ-45, PoE+ (TP-Link TL-SG2016P)
          Net Price: 159,00 EUR
          product card»
          #09296

          Smart switch, 16x 10/100/1000 RJ-45, 2x SFP, PoE+, 19" (TP-Link TL-SG2218P)

          • 150 W PoE Budget: 16× 802.3at/af-compliant PoE+ ports with a total power supply of 150 W*.
          • Full Gigabit Ports: 16× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • IPv6: IPv6 support with dual IPv4/IPv6 stack, MLD snooping, IPv6 neighbor discovery.
          Standards IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE802.3z,
          IEEE 802.3ad,
          IEEE 802.3x,
          IEEE 802.3az,
          IEEE 802.1d,
          IEEE 802.1s,
          IEEE 802.1w,
          IEEE 802.1q,
          IEEE 802.1p,
          IEEE 802.1x
          Copper ports 16x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
          SFP Slots 2× Gigabit SFP Slots
          Fan Quantity 1
          PoE Ports (RJ45) Standard 802.3at/af compliant,
          PoE+ Ports 16 Ports,
          PoE Power Budget 150 W
          Performance
          Bandwidth/Backplane 36Gbps
          MAC Address Table 8k
          Packet Forwarding Rate 26.8Mpps
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Dimensions 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240 V AC~50/60 Hz
          Max Power Consumption 181.4 W (110 V/60 Hz) (with 150 W PD connected),
          178.3 W (220 V/50 Hz) (with 150 W PD connected)
          Max Heat Dissipation 619.06 BTU/hr (110 V/60 Hz) (with 150 W PD connected),
          608.52 BTU/hr (220 V/50 Hz) (with 150 W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 16x 10/100/1000 RJ-45, 2x SFP, PoE+, 19" (TP-Link TL-SG2218P)
          Net Price: 202,00 EUR
          product card»
          #09143

          Smart switch, 16x 10/100/1000 RJ-45, 2x SFP, 19" (TP-Link TL-SG2218)

          • Full Gigabit Ports: 16× gigabit RJ45 ports and 2× gigabit SFP Slots provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • Standalone Management: Web, CLI (Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities
          Standards IEEE 802.3/i/u/ab/ad/x/d/s/w/q/p
          Copper ports 16x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
          SFP Slots 2× Gigabit SFP Slots
          Performance
          Bandwidth/Backplane 36Gbps
          MAC Address Table 8k
          Packet Forwarding Rate 26.8Mpps
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Dimensions 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240 V AC~50/60 Hz
          Power Consumption 12,3 W (220 V/50 Hz)
          Fan Quantity Fanless
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 16x 10/100/1000 RJ-45, 2x SFP, 19" (TP-Link TL-SG2218)
          Net Price: 111,00 EUR
          product card»
          #08531

          Smart switch, 16x 10/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link TL-SG1016DE)

          • 16 10/100/1000Mbps RJ45 ports
          • Provides network monitoring, traffic prioritization and VLAN features
          • Innovative energy-efficient technology reduces power output by up to 40%
          • Simple network set-up on top of plug-and-play connectivity
          • Centrally manage all Easy Smart Switches with Easy Smart Configuration Utility
          • 19" Rack-mounting Bracket
          Standards IEEE 802.3,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 16x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Packet flow control Flow-Control,
          Back-Pressure
          Switching Capacity 32Gbps
          MAC Address Table 8K
          Packet Buffer Memory 512KB
          Packet Forwarding Rate 23.8Mpps
          Jumbo Frame 10240Bytes
          Forwarding rate 14 880 pps (10 Mbps),
          148 800 pps (100 Mbps),
          1 488 000 pps (1000 Mbps)
          Dimensions 11.6x7.1x1.7 in. (294x180x44 mm)
          Operating Temperature 0℃~40℃ (32℉~104℉)
          Storage Temperature -40℃~70℃ (-40℉~158℉)
          Operating Humidity 10%~90% non-condensing
          Storage Humidity 5%~90% non-condensing
          Power internal,
          ~230V AC 50Hz
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 16x 10/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link TL-SG1016DE)
          Net Price: 57,80 EUR
          product card»
          #06276

          Smart switch, 16x 10/100/1000 RJ-45, PoE+, 19" Rack-mounting Bracket (TP-Link TL-SF1016PE)

          • 16 10/100/1000Mbps RJ45 ports
          • Equipped with 8 PoE+ supported ports to transfer data and power over a single cable
          • With a total PoE power budget of 110W, up to 30W per port
          • Works with IEEE 802.3af/at compliant devices, expanding home and office networks
          • Simple network set-up on top of plug-and-play connectivity
          • Web-based user interface and management utility simplify configuration
          Standards IEEE 802.3,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 16x 10/100/1000 Mbps RJ-45
          Fan Quantity 1
          PoE Ports Standard 802.3 at compliant,
          PoE Ports Port 1- Port 8,
          PoE Power Budget 110W,
          Power Supply 53W
          Performance:
          Switching Capacity 32Gbps
          Packet Forwarding Rate 23.81Mpps
          MAC Address Table 8K
          Packet Buffer Memory 4.1Mb
          Jumbo Frame 9KB
          Software features:
          Quality of Service Support Port-based/802.1p/DSCP priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping V1/V2/V3,
          Static Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention
          VLAN Supports up to 128 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Management Web-based GUI,
          Easy Smart Configuration Utility
          Transmission Method Store-And-Forward
          Dimensions 11.6x7.1x1.7 in. (294x180x44 mm)
          Operating Temperature 0℃~40℃ (32℉~104℉)
          Storage Temperature -40℃~70℃ (-40℉~158℉)
          Operating Humidity 10%~90% non-condensing
          Storage Humidity 5%~90% non-condensing
          Power 100-240VAC,
          50/60Hz
          Power Consumption 14.72W (110V/60Hz with no PD connected),
          131.42W (110V/60Hz with 110W PD connected)
          Max Heat Dissipation 50.22 BTU/h (with no PD connected),
          448.41 BTU/h (with 110W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty 5 years
          Manufacturer TP-Link
          Smart switch, 16x 10/100/1000 RJ-45, PoE+, 19" Rack-mounting Bracket (TP-Link TL-SF1016PE)
          Net Price: 128,00 EUR
          product card»


top

Page 7 of 43
