TP-LINK

TP-LINK Products

TP-LINK - Networking products

TP-LINK
TP-LINK
TP-LINK is a largest Chinese network hardware manufacturer for SOHO market. Company was founded in 1996. Their market share in networking products is still growing. TP-LINK cooperates with over 600 distributors in China and rest of the world. There are over 100 experienced engineers working for TP-LINK in two factories with 21 production lines. Perfect technical support and management system compliant with ISO9001:2000 gives warranty of reliability and stability of their devices. Quality of products was confirmed with a lot of awards in many independent device tests. TP-LINK is also manufacturing OEM versions of hardware for other network device manufacturers.

TP-LINK offers includes:
  • access points
  • routers
  • network cards
  • switches
  • media converters
  • modems

Manufacturer's website: http://www.tp-link.com

  • Computer Network Accessories
    • Switches
      • » GIGABIT ETHERNET / INTELLIGENT (SMART SWITCHES)
          #09033

          Smart switch, 16x 10/100/1000 RJ-45, 2x SFP, PoE+, 19" (TP-Link TL-SG1218MPE)

          • 16 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots
          • PoE power budget is up to 192W, making it ideal for small to medium business surveillance systems
          • Port Priority is able to guarantee the quality of sensitive application like video monitor
          • Intelligent power management can protect the switch from overload
          • QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimizing traffic for IPTV.
          Standards IEEE 802.3,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.3af,
          IEEE 802.3at,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 16x 10/100/1000 Mbps RJ-45
          SFP Ports 2 Gigabit SFP Ports
          Fan Quantity 2
          PoE Ports Standard 802.3 at compliant,
          PoE Ports Port 1- Port 16,
          PoE Power Budget 192W
          Performance:
          Switching Capacity 36 Gb/s
          Packet Forwarding Rate 23,8 Mb/s
          MAC Address Table 8K
          Packet Buffer Memory 4.1Mb
          Jumbo Frame 9KB
          Software features:
          Quality of Service Support Port-based/802.1p/DSCP priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping V1/V2/V3,
          Static Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention
          VLAN Supports up to 128 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Management Web-based GUI,
          Easy Smart Configuration Utility
          Transmission Method Store-And-Forward
          Dimensions 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm)
          Operating Temperature 0℃~40℃ (32℉~104℉)
          Storage Temperature -40℃~70℃ (-40℉~158℉)
          Operating Humidity 10%~90% non-condensing
          Storage Humidity 5%~90% non-condensing
          Power 100-240VAC,
          50/60Hz
          Power Consumption 18.73 W (220/50Hz. no PD connected),
          217.22 W (220/50Hz. with 192W PD connected)
          Max Heat Dissipation 63.89 BTU/h (no PD connected),
          741.15 BTU/h (with 192W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty 5 years
          Manufacturer TP-Link
          Smart switch, 16x 10/100/1000 RJ-45, 2x SFP, PoE+, 19" (TP-Link TL-SG1218MPE)
          Net Price: 168,00 EUR
          product card»
          #08532

          Smart switch, 24x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link TL-SG1024DE)

          • 24 10/100/1000Mbps RJ45 ports
          • Provides network monitoring, traffic prioritization and VLAN features
          • Innovative energy-efficient technology reduces power output by up to 40%
          • Simple network set-up on top of plug-and-play connectivity
          • Centrally manage all Easy Smart Switches with Easy Smart Configuration Utility
          • 19" Rack-mounting Bracket
          Standards IEEE 802.3,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 24x 10/100/1000 Mbps RJ-45
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Switching architecture / speed Store and Forward
          Packet flow control Flow-Control,
          Back-Pressure
          Switching Capacity 48Gbps
          MAC Address Table 8K
          Packet Buffer Memory 512KB
          Packet Forwarding Rate 35.7Mpps
          Jumbo Frame 10240Bytes
          Forwarding rate 14 880 pps (10 Mbps),
          148 800 pps (100 Mbps),
          1 488 000 pps (1000 Mbps)
          Dimensions 11.6x7.1x1.7 in. (294x180x44 mm)
          Operating Temperature 0℃~40℃ (32℉~104℉)
          Storage Temperature -40℃~70℃ (-40℉~158℉)
          Operating Humidity 10%~90% non-condensing
          Storage Humidity 5%~90% non-condensing
          Power internal,
          ~230V AC 50Hz
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 24x 10/100/1000 RJ-45, 19" Rack-mounting Bracket (TP-Link TL-SG1024DE)
          Net Price: 83,40 EUR
          product card»
          #09144

          Smart switch, 24x 10/100/1000 RJ-45, 4x SFP, PoE+, 19" (TP-Link TL-SG2428P)

          • 250 W PoE Budget: 24× 802.3at/af-compliant PoE+ ports with a total power supply of 250 W.
          • Full Gigabit Ports: 24× gigabit PoE+ ports and 4× gigabit SFP Slots provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • IPv6: IPv6 support with dual IPv4/IPv6 stack, MLD snooping, IPv6 neighbor discovery.
          Standards IEEE 802.3/i/u/ab/z/ad/x/d/s/w/q/p
          Copper ports 24x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
          SFP Slots 4× Gigabit SFP Slots
          PoE+ Ports(RJ45) Standard 802.3at/af compliant,
          PoE+ Ports 24 Ports,
          Power Supply 250 W
          Performance
          Bandwidth/Backplane 56Gbps
          MAC Address Table 8k
          Packet Forwarding Rate 41.7Mpps
          Packet Buffer Memory 4.1 Mbit
          Jumbo Frame 9 KB
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Dimensions 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power 100-240 V AC~50/60 Hz
          Power Consumption 32.1 W (110 V/ 60 Hz with no PD connected),
          308.6 W (110 V/ 60 Hz with 250 W PD connected)
          Max Heat Dissipation 109.53 BTU/h (with no PD connected),
          1052.94 BTU/h (with 250 W PD connected)
          Fan Quantity 2
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Smart switch, 24x 10/100/1000 RJ-45, 4x SFP, PoE+, 19" (TP-Link TL-SG2428P)
          Net Price: 254,00 EUR
          product card»
          #09138

          Smart switch, 26x 10/100/1000 RJ-45, 2x SFP, PoE+, 19" (TP-Link TL-SG1428PE)

          • 24 10/100/1000Mbps RJ45 PoE+ Ports Switch with 2 SFP Slots
          • PoE power budget is up to 250 W*, making it ideal for small to medium business surveillance systems
          • Priority Mode helps to guarantee the quality of sensitive application like video monitoring
          • PoE Auto Recovery enables system self-healing to guarantee the stable operation of PoE-connected devices
          • QoS is for smooth internet-surfing experience and IGMP Snooping is capable of optimizing traffic for IPTV
          • Intelligent power management can protect the switch from overload
          Standards IEEE 802.3,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3x,
          IEEE 802.3af,
          IEEE 802.3at,
          IEEE 802.1q,
          IEEE 802.1p
          Copper ports 26x 10/100/1000 Mbps RJ-45
          SFP Ports 2 Gigabit SFP Ports
          Fan Quantity 2
          PoE Ports Standard 802.3 at compliant,
          PoE Ports Port 1- Port 24,
          PoE Power Budget 250W
          Performance:
          Switching Capacity 56 Gb/s
          Packet Forwarding Rate 41.7 Mb/s
          MAC Address Table 8K
          Packet Buffer Memory 4.1Mb
          Jumbo Frame 9KB
          Software features:
          Quality of Service Support Port-based/802.1p/DSCP priority,
          Support 4 priority queues,
          Rate Limit,
          Storm Control
          L2 Features IGMP Snooping V1/V2/V3,
          Static Link Aggregation,
          Port Mirroring,
          Cable Diagnostics,
          Loop Prevention
          VLAN Supports up to 128 VLANs simultaneously (out of 4K VLAN IDs),
          MTU/Port/Tag VLAN
          Management Web-based GUI,
          Easy Smart Configuration Utility
          Transmission Method Store-And-Forward
          Dimensions 17.3 × 8.7 × 1.7 in. (440 × 220 × 44 mm)
          Operating Temperature 0℃~50℃ (32℉~122℉)
          Storage Temperature -40℃~70℃ (-40℉~158℉)
          Operating Humidity 10%~90% non-condensing
          Storage Humidity 5%~90% non-condensing
          Power 100-240VAC,
          50/60Hz
          Power Consumption 27 W (220/50Hz. no PD connected),
          304.7 W (220/50Hz. with 250W PD connected)
          Max Heat Dissipation 92.07 BTU/h (no PD connected),
          1039.03 BTU/h (with 250W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty 5 years
          Manufacturer TP-Link
          Smart switch, 26x 10/100/1000 RJ-45, 2x SFP, PoE+, 19" (TP-Link TL-SG1428PE)
          for special orders only
          Net Price: 205,00 EUR
          product card»
      • » GIGABIT ETHERNET / L2 MANAGED SWITCHES
          #09325

          Managed switch, 5x 10/100/1000 RJ-45, PoE++ (TP-Link SG2005P-PD)

          • Up to 200 m PoE Distance: Standard PoE Passthrough to doubles PoE source-to-device transmission distance from 100 m (328 ft) to 200 m (656 ft) without losing gigabit speeds, perfect for long-range surveillance cameras and access points.*
          • 1-Port Gigabit PoE++ In and 4-Port PoE+ Out: Supports up to 64 W / 44 W / 19 W/ 6 W PoE budget output when powered by 802.3bt Type 4 (90 W), - 802.3bt Type 3 (60 W), 802.3at, and 802.3af PoE, respectively.**
          • Outdoor Weatherproof: IP55 waterproof, dustproof, and UV-resistant enclosure. Operation temperatures of -40 to 60 °C and 4KV lightning protection further ensure stable operation against harsh outdoor conditions.
          • Easy Installation: Easy to mount to a wall or pole with the provided mounting kits to flexibly fit your needs.
          • Centralized Cloud Management: Integrates into Omada SDN for cloud access, remote management, and multi-site management.
          • Value-Added Features Foster Touchpoint Experiences: Static Routing, Access Control List (ACL), QoS, and VLAN.
          Standards IEEE 802.3i,
          IEEE 802.3u,
          IEEE 802.3ab,
          IEEE 802.3ad,
          IEEE 802.3af,
          IEEE 802.3at,
          IEEE 802.3bt,
          IEEE 802.3x,
          IEEE 802.1d,
          IEEE 802.1s,
          IEEE 802.1w,
          IEEE 802.1q,
          IEEE 802.1p,
          IEEE 802.1x
          Copper ports 5x 10/100/1000 Mbps RJ-45
          PoE Ports (RJ45) PoE In Port Port 5,
          Compliance with 802.3af/at/bt,
          PoE Out Ports Ports 1-4,
          compliance with 802.3af/at PoE
          PoE Power Budget ,
          64 W when powered by 802.3bt Type 4 (90 W),
          44 W when powered by 802.3bt Type 3 (60 W),
          19 W when powered by 802.3at,
          6 W when powered by 802.3af
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 10
          Packet Forwarding Rate 7,44 Mpps
          MAC Address Table 8 K
          Packet Buffer Memory 4.1 Mbit
          Jumbo Frame 9 KB
          Dimensions 3,9 × 1,5 × 6,7 in (100 × 38,5 × 170 mm)
          Fan Quantity 0
          Operating temperature -40°C ÷ 60°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power Obtain Power from 802.3af/at/bt PoE Source
          Max Power Consumption 71.5 W (when powered by 802.3bt Type 4 (90 W))
          Max Heat Dissipation 243.99 BTU/hr (when powered by 802.3bt Type 4 (90 W))
          Certificates CE,
          FCC,
          RoHS
          Manufacturer TP-Link
          Managed switch, 5x 10/100/1000 RJ-45, PoE++ (TP-Link SG2005P-PD)
          Net Price: 78,60 EUR
          product card»
          #09178

          Managed switch, 8 slide-in 10G SFP+ slot, 19" (TP-Link TL-SX3008F)

          • 10G Lightning-Fast Connections: 8× 10 Gbps SFP+ Ports enable high-bandwidth connectivity and non-blocking 160 Gbps switching capacity.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Easy and convenient management with cloud access and Omada app.
          • Static Routing: Route internal traffic for the efficient use of network resources.
          • Robust Security Strategies: Keep your data safe with systems including IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, and Radius Authentication.
          • Voice and Video Application Optimization: L2/L3/L4 QoS and IGMP snooping.
          • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities
          Ports 8x 10G SFP+
          Additional ports 1× RJ45 Console Port,
          1× Micro-USB Console Port
          Fan Quantity Fanless
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 160
          Packet Forwarding Rate 119,04 Mpps
          MAC Address Table 32K
          Jumbo Frame 9 KB
          Housing / case type Rack Mountable
          Dimensions 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
          Operating temperature 0°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~230VAC 50/60Hz
          Max Power Consumption 15.46 W (110 V/60 Hz)
          Max Heat Dissipation 52.75 BTU/h (110 V/60 Hz)
          Certificates CE,
          FCC
          Warranty period 5 years
          Manufacturer TP-Link
          Managed switch, 8 slide-in 10G SFP+ slot, 19" (TP-Link TL-SX3008F)
          for special orders only
          Net Price: 201,00 EUR
          product card»
          #09145

          Managed switch, 8x 10/100/1000 RJ-45, 2 slide-in SFP slot, 19" Rack-mounting Bracket (TP-Link TL-SG3210)

          • Full Gigabit Ports: 8× gigabit RJ45 ports and 2× gigabit SFP Slots provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities
          Standards IEEE 802.3 10Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 8x 10/100/1000 Mbps RJ-45
          Free slots 2x 1000 Mbps SFP
          Additional ports 1× RJ45 Console Port,
          1× Micro-USB Console Port
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 20
          MAC address memory 8000
          Packet Forwarding Rate 14.89 Mpps
          Housing / case type 11.6",
          metal,
          19" brackets included
          Dimensions 294x180x44 mm
          Operating temperature 0°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~230VAC 50/60Hz
          Max Power Consumption 6.84 W (220 V/50 Hz)
          Max Heat Dissipation 23.33 BTU/h (220 V/50 Hz)
          Certificates CE,
          FCC
          Warranty period 5 years
          Manufacturer TP-Link
          Managed switch, 8x 10/100/1000 RJ-45, 2 slide-in SFP slot, 19" Rack-mounting Bracket (TP-Link TL-SG3210)
          Net Price: 86,20 EUR
          product card»
          #09146

          Managed switch, 8x 100/1000/2500 RJ-45, 2 slide-in 10G SFP slot, PoE+, 19" (TP-Link TL-SG3210XHP-M2)

          • 2.5G PoE+ Ports for WiFi 6: 8× 2.5 Gbps ports smash the gigabit barrier and unlock the full potential of WiFi 6 APs.
          • 10G Lightning-Fast Uplink: 2× 10 Gbps SFP+ slots enable high-bandwidth connectivity and non-blocking switching capacity.
          • 240 W PoE Budget: 8× 802.3at/af-compliant PoE+ ports with a total power supply of 240 W*.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          Standards IEEE 802.3 10Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 8x 100/1000/2500 Mbps RJ-45
          Free slots 2x SFP 10G
          Additional ports 1× RJ45 Console Port,
          1× Micro-USB Console Port
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 80
          Packet Forwarding Rate 59,52 Mpps
          MAC Address Table 16 K
          Jumbo Frame 9 KB
          Housing / case type Rack Mountable
          Dimensions 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
          Fan Quantity 2
          Operating temperature 0°C ÷ 50°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~230VAC 50/60Hz
          Max Power Consumption 17.24 W (110V/60Hz) (no PD connected),
          291.49 W (110V/60Hz) (with 240 W PD connected)
          Max Heat Dissipation 58.82 BTU/h (110 V/60 Hz) (no PD connected),
          994.56 BTU/h (110 V/60 Hz) (with 240 W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Managed switch, 8x 100/1000/2500 RJ-45, 2 slide-in 10G SFP slot, PoE+, 19" (TP-Link TL-SG3210XHP-M2)
          for special orders only
          Net Price: 348,00 EUR
          product card»
          #09268

          Managed switch, 24x SFP, 4 slide-in 10G SFP+ slot, 19" (TP-Link TL-SG3428XF)

          • 10G Lightning-Fast Uplink: 4× 10 Gbps SFP+ slots enable high-bandwidth connectivity and non-blocking switching capacity.
          • Gigabit Fiber Speeds: 20× gigabit SFP ports and 4× gigabit SFP/RJ45 Combo ports s offer high-speed and reliable connections to other switches and devices.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities
          Standards IEEE 802.3 10Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 4x combo 10/100/1000 Mbps RJ-45/SFP
          SFP ports 20x SFP
          Free slots 4x 10G SFP+
          Additional ports 1× RJ45 Console Port,
          1× Micro-USB Console Port
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Fan Quantity 1 Fan
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 128
          Packet Forwarding Rate 95,23 Mpps
          MAC Address Table 16K
          Jumbo Frame 9 KB
          Housing / case type Rack Mountable
          Dimensions 17.3 × 8,7 × 1.7 in (440 × 220 × 44 mm)
          Operating temperature 0°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~230VAC 50/60Hz
          Max Power Consumption 35,7 W (110 V/60 Hz)
          Max Heat Dissipation 121.81 BTU/h (110 V/60 Hz)
          Certificates CE,
          FCC
          Warranty period 5 years
          Manufacturer TP-Link
          Managed switch, 24x SFP, 4 slide-in 10G SFP+ slot, 19" (TP-Link TL-SG3428XF)
          Net Price: 467,00 EUR
          product card»
          #09148

          Managed switch, 24x 10/100/1000 RJ-45, 4 slide-in SFP slot, PoE+, 19" (TP-Link TL-SG3428MP)

          • 384 W PoE Budget: 24× 802.3at/af-compliant PoE+ ports with a total power supply of 384 W*.
          • Full Gigabit Ports: 24× gigabit PoE+ ports and 4× gigabit SFP Slots provide high-speed connections.
          • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
          • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
          • Static Routing: Helps route internal traffic for more efficient use of network resources.
          • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
          • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
          • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities.
          Standards IEEE 802.3 10Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 24x 10/100/1000 Mbps RJ-45
          Free slots 4x 1000 Mbps SFP
          Additional ports 1× RJ45 Console Port,
          1× Micro-USB Console Port
          PoE+ Ports(RJ45) Standard 802.3at/af compliant,
          PoE+ Ports 24 Ports,
          up to 30 W per port,
          Power Budget 384 W
          Auto MDI/MDI-X yes
          Auto-negotiation (Nway) yes
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 56
          Packet Forwarding Rate 41.66 Mpps
          MAC Address Table 16K
          Jumbo Frame 9 KB
          Housing / case type Rack Mountable
          Dimensions 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)
          Fan Quantity 2
          Operating temperature 0°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power internal,
          100~230VAC 50/60Hz
          Max Power Consumption 31.0 W (110 V/60 Hz) (no PD connected),
          463.8 W (110 V/60 Hz) (with 384 W PD connected)
          Max Heat Dissipation 105.78 BTU/h (110 V/60 Hz) (no PD connected),
          1582.49 BTU/h (110 V/60 Hz) (with 384 W PD connected)
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          Managed switch, 24x 10/100/1000 RJ-45, 4 slide-in SFP slot, PoE+, 19" (TP-Link TL-SG3428MP)
          Net Price: 321,00 EUR
          product card»


top

Page 8 of 43
