Output | |
---|---|
DC Voltage | 24V |
Rated current | 10A |
Current Range | 0÷10A |
Rated Power | 240W |
Ripple & noise (max.) | 100mVp-p |
Voltage adjustment range | 24÷28V |
Voltage tolerance | ±1.0% |
Line regulation | ±0.5% |
Load regulation | ±1.0% |
Setup & rise time | 1500ms & 60ms/230VAC at full load, 3000ms & 40ms/115VAC at full load |
Hold up time (typ.) | 20ms/230VAC at full load, 20ms/115VAC at full load |
Input | |
Voltage range | 88÷264VAC, 124÷370VDC |
Frequency range | 47÷63Hz |
Power factor (typ.) | 0.93/230VAC at full load, 0.96/115VAC at full load |
Efficiency (typ.) | 94% |
AC current (typ.) | 2.6A/115VAC, 1.3A/230VAC |
Inrush current (typ.) | 33A/115VAC cold start, 65A/230VAC cold start |
Leakage current | <1mA/240VAC |
Protection | |
Overload | 110%÷150% rated output power, protection type - constant current limiting - recovers automatically after fault condition is removed |
Overvoltage | 29÷33V, protection type - shut down o/p voltage & re-power on to recover |
Over temperature | 95°C ±5°C (TSW1) detect on heatsink of power transistor, protection type - shut down o/p voltage & re-power on to recover |
Environment | |
Working temperature | -25°C ÷ 70°C |
Working humidity | 20÷95% RH non-condensing |
Storage temperature | -40°C ÷ 85°C |
Storage Humidity | 10÷95% RH |
Temperature coefficient | ±0.03%/°C (0÷50°C) |
Vibration (component) | 10÷500Hz, 2G 10min./1cycle, 60min. each along X Y Z axes |
Vibration (mounting) | compliance to IEC60068-2-6 |
Safety & EMC | |
Safety standards | UL508, UL60950-1, TUV EN60950-1 |
Withstand voltage | I/P-O/P 3kVAC, I/P-FG 1.5kVAC, O/P-FG 0.5kVAC |
Isolation resistance | I/P-O/P 100MΩ/500VDC, I/P-FG 100MΩ/500VDC, O/P-FG 100MΩ/500VDC |
EMI conduction & radiation | EN55011, EN55022 (CISPR22), EN61204-3 Class B |
Harmonic current | EN61000-3-2, EN61000-3-3 |
EMS immunity | EN61000-4-2/3/4/5/6/8/11, ENV50204, EN55024, EN61000-6-2 (EN50082-2), heavy industry level criteria A |
Others | |
MTBF | min. 169300h MIL-HDBK-217F (25°C) |
Dimension (W x H x D) | 63mm x 125,2mm x 113,5mm |
Weight | 1,03kg |
Net Price: 91,40 EUR Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
