HARDWARE FEATURES: | |
---|---|
Ports | 1 * 10/100/1000M Ethernet Port (RJ45) |
Plug Type | EU |
Button | RE (Range Extender) Button, Reset Button, LED Button, Power Button |
Power Consumption | About 12W |
Wireless Standards | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Dimensions ( W x D x H ) | 6.4x 3.4 x 1.6 in. (163 x 86 x 40mm) |
Antenna Type | 4 x external |
WIRELESS FEATURES | |
Frequency | 2.4GHz & 5GHz |
Signal Rate | 5GHz Up to 1733Mbps, 2.4GHz Up to 800Mpbs |
EIRP | <20dBm(2,4GHz) <23dBm(5GHz) |
Reception Sensitivity | 5GHz 11a 6Mbps -96dBm@10% PER, 11a 54Mbps -78dBm@10% PER, 11ac HT20 mcs8 -69dBm@10% PER, 11ac HT40 mcs9 -66dBm@10% PER, 11ac HT80 mcs9 -63dBm@10% PER, 2,4GHz 11g 54M -79dBm@10% PER, 11n HT20 mcs7 -77dBm@10% PER, 11n HT40 mcs7 -74dBm@10% PER |
Wireless Modes | Range Extender |
Wireless Functions | WMM (Wi-Fi Multimedia), Wireless Statistic, Domain Login Function |
Wireless Security | 64/128-bit WEP, WPA-PSK / WPA2-PSK |
OTHERS | |
Certification | CE, FCC, RoHS |
Package Contents | RE650, Quick Installation Guide |
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7,8,10, MAC OS, NetWare, UNIX or Linux. |
Environment | Operating Temperature 0°~40° (32°~104°), Storage Temperature -40°~70° (-40°~158°), Operating Humidity 10%~90% non-condensing, Storage Humidity 5%~90% non-condensing |
Warranty | 2 years limited warranty. Advanced replacement service is available. |
Manufacturer | TP-Link |
* For special orders only
Net Price:
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
